Welcome to
Future An Expectation of Advancement or Progessive Development
Main Paragraph of 20-30 words explaining the key differentiation of BEM against other competitors/ Promo Paragraph for launch of EV.
Connected Trucks
The next generation telematics technology maximizes returns for every transporter by empowering them to maximize the operational efficiency and productivity.
It provides powerful insights on vehicle health and performance by deploying:
- IoT
- Machine Learning
- Artificial Intelligence
Here’s how it offers unparallel and unprecedented value to customers:
FLEET MANAGEMENT
Operations is automated and saves on manhours with
- Tracking anomalies
- Option to replay the entire route on the map, etc.
GEO FENCING
- Auto alert if any deviation from prescribed route
FUEL MANAGEMENT
- Very reliable and highly accurate fuel consumption report
- Detailed graphical analysis
TRIP MANAGEMENT
Check-in Check-out details are captured along with
- Trip fuel economy
- Distance
- Travel time, etc.
VEHICLE TRACKING
- Real time tracking of Vehicle
DRIVER MANAGEMENT
Drivers are scored on traits such as
- Idling
- Free Running
- Hard Braking
- Over Speeding
- Higher Gear Utilization, etc.
REPORTS & ANALYTICS
Highlights monetary losses by
- Behaviour Analysis of 20+ exceptions
- Idling dashboard, etc.
ALERTS & NOTIFICATION
Following alerts prevent accidents and damage to the vehicle
- Free Running
- Hard Braking
- Harsh Acceleration
- Over Speeding, etc.
PROACTIVE VEHICLE SERVICE SUPPORT
Increased vehicle uptime and cost-efficient spare part inventory by
- Tracking service schedules as per recommended intervals
- Tracking service consumables
- Schedule tasks as tire change and alignment on long haul cargo trucks
Benefits
Reduction in Breakdown events possible with predictive analytics
75%
Improvement in Driver Behavior
~30%
Increase in Asset availability due to reduced failure
~30%
Maintenance Costs reduction via predictive approach
~30%
Swappable Battery Product Info
| Property | Description | |
|---|---|---|
| Product Specificaton | Product Specificaton | Product Specificaton |
| Product Specificaton | Product Specificaton | Product Specificaton |
| Product Specificaton | Product Specificaton | Product Specificaton |
| Product Specificaton | Product Specificaton | Product Specificaton |
| Product Specificaton | Product Specificaton | Product Specificaton |
Technical Perameters of Sawpping Station
| Sr No. | Pramenter | Detail |
|---|---|---|
| 1 | Battery Replacement time | (<5 min) |
| 2 | Battery swap success rate | 99.90% |
| 3 | Charging time | (<1Hr) |
| 4 | Battery swapping ability | 72 times/24Hr |
| 5 | No. of swappable battery | 4 Cradle 3 Charging |
| 6 | Total area required (Including Diveway) | 96 sqm |
| 7 | Total area required (Without Driveway) | 36 sqm |
| 8 | Overall Dimenssions (LXWXH) in meter | 12X3.6X5.3 |
| 9 | Ambient temp | -30 °C to 55°C |
| 10 | Rated Load | 3.8 T |
| 11 | Fire Protection | Temp Sensor, Smoke Detector, Dry Poweder Fire Extinguisher |
| 12 | Power Source | 415V AC |
| 13 | Power Demand | 800 kVA |
| 14 | Operation method | Fully Automatic |
| 15 | Vehcle position (Forward/Reverse) | +/-300 mm |
| 16 | Vehcle position (Left/Right) | +/-250 mm |
| 17 | Battery positioning | Laser |
| 18 | Dislplay (operation) | 12 inch LCD Touchscreen |
| 19 | Vehicle Guidance | RFID vehicle recognization,Display for driver guidance |
| 20 | Station and charger Cooling | Forced Air cooling |
| 21 | Battery Cooling | Liquid Cooling |
Technical Perameters of Dual gun Charger
| Sr No. | Pramenter | Detail |
|---|---|---|
| 1 | DC Output Voltage Rating | 200- 750 VDC (1000 VDC on request) |
| 2 | Max. DC Output Current | 200 A per output |
| 3 | DC Power Rating | 240 kW Max |
| 4 | Output Plug | CCS2 |
| 5 | Number of Plug | 2 |
| 6 | Efficiency | ≥95% for 50% ≤ load ≤ 100% at Nominal IP Voltage |
| 7 | Capacity | 240kW |
| 8 | Gun | Dual gun |
| 9 | Input Voltage | 415VAC, 3-phase / L1, L2, L3,N, PE |
| 10 | Input Voltage Range | 320VAC - 520VAC |
| 11 | Input Frequency Range | 45Hz - 55Hz |
| 12 | Power Factor | >0.98 |
| 13 | THD | (<5% ) |
| 14 | Safety Parameters | Over current, Under voltage, Over voltage, Residual current, Surge protection, Short circuit, Over temperature, Ground fault, Insulation fault, Emergency Stop |
| 15 | Battery Backup | 1 hour (optional) |
| 16 | Display | 7" LCD Touch Screen |
| 17 | Support Language | English |
| 18 | Emergency Switch | Available (Mushroom red switch) |
| 19 | Charging Operation | Cyclic and Simultaneous |
| 20 | Charge Option | Auto Charge, Mode Selection (Time/Energy/SOC) |
| 21 | Visual Indication | Presence of supply, Status of Charging, Error |
| 22 | User Authentication | RFID/APP/OTP/QR (as per requirement) |
| 23 | EVSE and EVCC | PLC in CCS 2 (DIN 70121 & ISO 15118), CAN in GB/T 27930 |
| 24 | EVSE and CMS (Billing and Payment Service) | Ethernet (standard); 3G/4G (optional), OCPP v1.6J (Optional) |
| 25 | Ingress Protection | IP 54 |
| 26 | Cooling | Forced air cooling |
| 27 | Dimension (H x W x D) | 1850 x 650 x 510 (mm) |
| 28 | Charging Cable Length | 5 meters (Length as per Customer Request) |
| 29 | Operating Temperature | -20°C to 75°C (de-rating from 55°C) |
| 30 | Storage Temperature | -20°C to 80°C |
| 31 | Altitude | Up-to 2000 meters (de-rating above 2000 meters) |
| 32 | Humidity | 5% to 95% non-condensing |
Product Description
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Etiam eu turpis molestie, dictum est a, mattis tellus. Sed dignissim, metus nec fringilla accumsan, risus sem sollicitudin lacus, ut interdum tellus elit sed risus. Maecenas eget condimentum velit, sit amet feugiat lectus. Class aptent taciti sociosqu ad litora torquent per conubia nostra, per inceptos himenaeos. Praesent auctor purus luctus enim egestas, ac scelerisque ante pulvinar. Donec ut rhoncus ex. Suspendisse ac rhoncus nisl, eu tempor urna. Curabitur vel bibendum lorem. Morbi convallis convallis diam sit amet lacinia. Aliquam in elementum tellus.
The LNG powered 4×2 tractor is the best-in-class providing a Cleaner Today and a Greener Tomorrow.
- OTHER ADVANTAGES
- Superior pickup in all conditions
- Excellent load pulling capability in all types of load and road conditions
- Delivering heavy-duty performance
- Lowest fuel costs
- Best-in-class operating economics
- State-of-the-art connected truck with cutting edge features
- Superior comfort and convenience
Specification
| Model | FPT NEF 6.7 LNG BSVI |
| Ltrs (L) | 6.7 L |
| Cylinders | 6 |
| Max Power (PS) | 280 PS @ 2200 rpm |
| Max Torque (Nm) | 1000 Nm @ 1200-1900 rpm |
| ATS | 3 Way Catalyst |
| Type | Mechanical |
| No. of Gears / Speeds | 9+1R |
| Clutch type | Single Plate - Dry - Organic |
| Clutch Dia (mm) | 395 |
| Type | Single / Hub Reduction Axle |
